P6 High resolution Outdoor full color led display use for advertising video wall
Products Feature
1) It is very easy to calculate the size of LED screen. It can be exactly 4*3m, 6m*4m, 8m*4.5m etc. ( 4m*3m is 4:3 ratio and 8m*4.5m is 16:9 ratio, perfect to show video )
2) Ultra-thin and Super-light: only 50KG per cabinet of 960mmW*960mm and depth is only 130mm, can stand on floor independently.
3) The appearance is very simple and elegant, looks very high end.
4) With specially designed fast lock system, easy to install and dismantle
5) The new structure design enables diversified installation to meet the hanging-up and stacking requirements.
6) .High contrast rate up to 5000:1 by using black LED
7) .High refresh rate with NOVA control system, no scaning line when photographed.
8) . Due to the light weight and low power consumption, it can reduces the labor cost, operating cost and transportation cost
9) 14 bit color,65536 gray scale, showing very clear and vivid video and images.
10) Good thermal design, excellent heat dissipation even no fan installation.
Parameters of BST-OD-6
| Model | PH6 |
| Pixel Pitch | 6mm |
| Unit Size | 960mm x 960mm |
| LED Type | SMD3535 |
| Pixel / Unit | 160x160 |
| Unit Weight | 55kg |
| Viewing Angle | H140° V140° |
| Application | Storage-40~60° C, Working-20~50° C |
| Protection Level | IP65 |
| Power Consumption | 500W/sqm Max |
| 240W/sqm Ave. |
| Driving | 1/4 scan |
| Frame Refresh | ≥ 60Hz |
| Data Refresh Rate | 1, 200~4, 000Hz |
| Processing | 16bit |
| Max Brightness | 6, 000-7, 000nits |
| Power Supply | AC90-240V, 50~60Hz |
| MTBF | ≥ 1, 000 Hours |
| Life Span | ≥ 50, 000 Hours |
| Pixel Failure | < 0.0003 |
Testing
Accessory
Application:
Entertainment events,Commercial advertising,Stadium perimeter, such as banks,schools, telecommunications, mobile media, night club, business establishments, customs, stadiums, studio, stock exchange centers, bus station, shopping malls, railways, airports, harbors, etc;
Our Services
1. Provides all LED display relative solution, like installation drawing etc.
2. Have free training about how to use and maintain LED display with our professional engineer.
3. Provide free spare parts for future urgent need.
4. Technical Support: We could send our engineer to guide the installation for you. But the relevant cost should be paid by your esteemed company such as accommodation & round-trip ticket.
5. Professional engineer in service after sales, 18/7 for any inquiry.
6. All other service request will be considered in BST , please contact with sales in details.
FAQ
Why choose BST
| 1. Our LED display signs have the ISO9001:2000 Quality System Certification; |
| 2. CE & RoHS Certification of our LED display signs; |
| 3. Excellent Technical Innovation; |
| 4. Contract Performance and Credibility; |
| 5. Price performance ratio; |
| 6. Modular LED display screens; |
| 7. LED displays with high brightness LED's; |
| 8. High ecperiences and know-how LED display products; |
| 9. Post sale assistance (after sale); |
| 10. Our LED display screens have a warranty up to 1-3 years (depending on configuration). |
| 11. Personalized sale and less than 24 hours response on all inquiries; |
